DIN17102 StE355 Pressure vessel steel plate Equivalent Material

DIN17102 StE355 Pressure vessel steel plate Equivalent Material

Bebon steel can supply DIN17102 StE355 Pressure vessel steel plate Equivalent Material price and specification ,we are steel suppliers and manufacturer,you can contact us to get DIN17102 StE355 Pressure vessel steel plate Equivalent Material application and other informations.

StE355 steel plate is a kind of material for boiler and pressure vessel steel. DIN17102 StE355 Pressure vessel steel plate has the good grain and Mechanical properties.DIN17102 StE355 steel sheet is characterized by a minimum yield strength of 295-335 MPa and by good weldability, so StE355 steel plate is mainly used to for manufacturing boilers, pressure vessels and pipes transporting hot liquids.

DIN17102 StE355 Pressure vessel steel plate Equivalent Material

DIN17102 StE355 steel Specification

Thickness:6-550mm

Width:1500-4020mm

Length:3000-18000mm

StE355 steel sheet Chemical composition(%)

C≤0.20 Si:0.10-0.50 Mn:0.90-1.55 P≤0.035 S≤0.030 N≤0.02 Al≤0.02 Cr≤0.30 Cu≤0.20 Mo≤0.08Ni≤0.30 Nb≤0.05 V≤0.10 Nb+Ti+V≤0.12

StE355 steel Mechanical properties

Yiled strength Mpa:295-335 Tensile strength Mpa:450-630 Elongation(%):22

Equivalent grades of grade DIN17102 StE355 Pressure vessel steel plate

USA

EN10028-2

EN10028-3

UNI 5859

BS 1501

JIS3103

A537CL1

P355GH

P355N

Fe 5101KW

224Gr..460,490,400,430

SB 480

Technique: Hot Rolled

Surface Treatment: uncoated

Trade Terms: FOB, CFR, CIF

Payment Terms: T/T, Irrevocable at sight L/C

Delivery State: HR,TMCP, Q&T, N, T, N&T,Z15,Z25,Z35, Ultrasonic test, Sharp V-notch impact test, HIC test ,etc

Bebon International continuously uphold the purpose of mutual benefit, we always provide StE355 Pressure vessel steel plate of preferential prices and integrated services. If you place an order about the DIN17102 StE355 steel plate, we will give you a satisfactory answer.
