S355J0W corten steel plate under EN 10155 standard which is a kind of hot rolled products with improved atmospheric corrosion resistance.
Steel Name: S355J0W corten steel plate, S355J0W steel plate, S355J0W steel sheet, S355J0W atmospheric corrosion resistance steel, S355J0W Structure plate
S355J0W corten steel plate specification:
Steel Grade: S355J0W Steel Standard: EN 10025-5
Thickness:2mm-450mm, Width:1000mm-4200mm, Length:3000mm-18000mm
S355J0W chemical analysis:
|
|
C |
Si |
Mn |
P |
S |
Cu |
Cr |
Ni |
|
max |
max |
max |
max |
max. |
max |
max |
max |
|
|
S355 JOW |
0.13 |
0.4 |
0.20-1.66 |
0.035 |
0.03 |
0.25-0.55 |
0.40-0.80 |
0.65 |
S355J0W mechanical property:
|
S355J0W |
Thickness(mm) |
S355J0W Tensile (MPa) |
Elongation (%) |
Min Impact Energy |
||
|
S355J0W |
≤16mm |
Min 355Mpa |
470-630Mpa |
22 |
0 |
27J |
|
16-40mm |
Min 345Mpa |
470-630Mpa |
22 |
0 |
27J |
|
|
The min impact energy is longitudinal energy |
||||||
S355J0W corten steel surface treatment: Shot blasting and painting or coated.
S355J0W corten steel plate application:
S355J0W corten steel plate is used for shipping containers,steel bridges,vessels and tanks for preventing atmospheric corrosion usage.
S355J0W tests: Tension test, Impact test, Ultrasonic Examination, etc.
S355J0W impact test: S355J0 plate adopt 0 temperature impact test with 27J.
To find out more informational about S355J0W corten steel plate and to receive a competitive quotation for the supply of S355J0W material, please CLICK HERE to contact us.
