Fe 510 steel mechanical properties and dimensions

Fe 510 steel is a structural billet for structural applications. Fe 510 is a material class and designation defined in the ISO 630 standard. ISO 630 is the international material standard for billets used for general structural purposes. Fe 430 steel is comparable to this type of steel.

Chemical composition of Fe 510 steel
Fe 510 maximum percentage of Carbon is 0.220.

Fe 510 maximum percentage of Manganese is not defined.

Fe 510 maximum percentage of Phosphorous is 0.040.

Fe 510 maximum percentage of Sulphur is 0.040.

Fe 510 maximum percentage of Nitrogen is 0.009.

Mechanical properties of Fe 510 steel: The tensile strength of Fe 510 steel is expressed in Newtons per millimeter. It must be at least 510 N/mm2 (MPa) and up to 630 N/mm2 (MPa). Fe 510 steel has a minimum yield strength of 355 N/mm2 (MPa), less than 16 mm, 345 N/mm2 (MPa), 16 mm to 40 mm, 335 N/mm2 (MPa), 40 mm to 60 mm. The minimum percentage range for elongation is 23% thickness.

Dimensions of Fe 510 steel: The applicable thickness of this Fe 510 material as defined in ISO 630 varies from 10 mm to 60 mm.
